Claber Medium-Jet Pop Up Sprinkler – 90474

The Claber Medium-Jet Pop Up Sprinkler is a reliable, versatile and easy to install pop-up sprinkler designed for medium-sized gardens. With a working range that can be adjusted from 40° to 360° and with the use of interchangeable nozzles, this pop-up sprinkler can be set to cover a distance from 4m to 9m. The Medium-Jet Pop Up Sprinkler can be set before installation and after installation in a static position, or during operation. A special mechanism avoids damage to the gears during regulation. For more details for operation at different running pressure, please

download the PDF user guide

.

Product Details:

• Ideal for medium-sized gardens.
• Adjustable water flow with 5 interchangeable nozzles.
• Maximum jet width: 9m radius.
• An adjustable arc between 40-360°.
• 1/2″ female BSP threaded inlet (bottom).
• Simple, hassle-free installation.
• Heavy-duty construction for reliability.

Performance Information

 Performance @ 1 BAR Pressure

Nozzle Size	Litres Per Min	Range (m)
0.75	2.7 l/min	4.8 metres
1	4.4 l/min	5.8 metres
1.5	4.5 l/min	6.7 metres
2	6.0 l/min	7.2 metres
3	9.4 l/min	8.0 metres



Performance @ 2 BAR Pressure

Nozzle Size	Litres Per Min	Range (m)
0.75	2.8 l/min	5.0 metres
1	4.8 l/min	5.9 metres
1.5	5.1 l/min	6.9 metres
2	6.6 l/min	7.5 metres
3	10.0 l/min	8.4 metres



Performance @ 3 BAR Pressure

Nozzle Size	Litres Per Min	Range (m)
0.75	3.1 l/min	5.2 metres
1	5.8 l/min	6.3 metres
1.5	6.7 l/min	7.2 metres
2	8.3 l/min	8.1 metres
3	11.8 l/min	9.0 metres
